Pneumatic DN100 Outlet Dome Valve CH0342D-00

Pneumatic DN100 Outlet Dome Valve CH0342D-00

Introduction:

The outlet dome valve DN100 CH0342D-00 is specially used in the pneumatic conveying system,

and can also be provided to customers as an independent product.

Applications in industry include power, food, medicine, chemical, plastic, mining, steel and other industries.

Commonly used conveying materials include: grinding materials, particles, powder, ash, chemicals, ores, coal, fragile products, etc.

The outlet dome valve DN100 CH0342D-00 is mainly equipped with: sector cylinder DN100 A1096, limit switch A1011,

valve body DN100 CP26,048B-00, dome DN1100 CP1165C-00, transmission shaft DN1100 CP11,714E-00, combined bearing DN100 P3884E-00,

V-shaped dust ring ￠ 50 DN100 M1006, shaft seat DN100 CP18,630E-00 VARI seal ring ￠ 30 DN100 M1243, spacer ring DN100, 80 CP2728C-00,

spring cylindrical pin ￠ 10X60 DN100 GB879-86, coupling DN100 CP22,060D-01, Spring cylindrical pin ￠ 10X55 DN100 GB879-86, O-ring ￠ 30 DN100 M1242,

sleeve ring DN100 CP29768D-00, support ring DN100 CP29767D-00, plug-in seal ring DN100 P1586C-01, O-ring DN100 M5204, plug-in seal ring DN100 P17458C-01,

top plate DN80 CP29769D-00, seal assembly DN100 M3227, bottom joint DN100 CP4353B-00, etc

Technical Features:

① No obstructed material flow in the whole chamber

② Simple and reliable design

③ Flexible opening and closing, can turn off dynamic and static material columns

④ Complete specifications and dimensions: DN50-DN300

⑤ It can form a firm pressure seal when closing

⑥ It can withstand the temperature of - 20 ℃ to 480 ℃

⑦ Long service life and low maintenance

⑧ The material conveying system of the power plant operates normally, and the service life of the plug-in seal ring is more than one year
